A.O. Smith
Sale ProLine XE® Voltex® AL 66-Gallon Smart Hybrid Electric Heat Pump Water Heater, 4.5 kW, 208V, 1-Phase, 2 Element, Indoor, Dual Magnesium Anodes, Side T&P, Interlock Wiring, 2

ProLine XE® Voltex® AL 66-Gallon Smart Hybrid Electric Heat Pump Water Heater, 4.5 kW, 208V, 1-Phase, 2 Element, Indoor, Dual Magnesium Anodes, Side T&P, Interlock Wiring, 2" Insulation, 100393114


ProLine XE® Voltex® AL 66-Gallon Smart Hybrid Electric Heat Pump Water Heater, 4.5 kW, 208V, 1-Phase, 2 Element, Indoor, Dual Magnesium Anodes, Side T&P, Interlock Wiring, 2" Insulation

  • 3657.88$3,657.88
    $6,883.90
  • Currently not in Stock
  • Free Shipping!
  • Brand: A.O. Smith
  • Model # 100393114

Qty

Share by Email Add to Houzz Tweet Pin This Share

The Voltex AL Smart Hybrid Electric heat pump water heater from A. O. Smith is the most cost-effective, energy-efficient option available for consumers who want to save money on their utility bills. Voltex AL combines annual savings of almost $600 per year* on utility bills with new leak protection features to support homeowner peace of mind like leak detection and optional automatic water shutoff.Featuring a 66-gallon tank, the HPTS-66 is the most efficient water heater on the market with a 3.70 Uniform Energy Factor (UEF).This heat pump technology delivers tremendous savings by generating heat through the heat pump technology instead of the heating elements. It offers premium features including a user-friendly display, vacation mode to save money while you are away, and a heavy duty anode that protects your tank for 10 years. In addition to the heat pump technology, this model also has two heating elements that help the water heater recover quickly during periods of high demand. This Heat Pump is Northwest Energy Efficiency Alliance (NEEA) Tier 3 qualified.This ProLine® XE water heater is designed with A. O. Smith's superior commercial-grade tank protection. Advanced tank features include stainless steel CoreGard™ anode rod, Blue Diamond® glass lining and DynaClean™ automatic sediment-cleaning system, all designed to help protect the tank from the corrosive effects of water and extend the life of the water heater. All of these features are accompanied by a 10-year limited tank warranty.A. O. Smith’s ProLine® water heaters are residential products built to commercial-grade standards and are only available for purchase through professional wholesalers and contractors.

Guides & Documents Spec Sheet Manual Service Handbook Warranty
All Type Of Item Water Heater
Anode Rod Type Dual Magnesium Anodes
ASME Certified No
Capacity (Gallons) 66
Classification Residential Hybrid Electric Heat Pump
Connection Size 4-Mar
Digital Display Yes
Family Description ProLine XE® Voltex® AL 66-Gallon Smart Hybrid Electric Heat Pump Water Heater
Family Name HPTS-66
Hazmat No
High Altitude Max 0 FT
High Altitude Min 0 FT
Installation Type INDOOR
Insulation Thickness (in) 2
Phase 1
Product Tier VOLTEX
Rated Storage Volume 67
Rating Plate Model Number HPTS-66 210
Serial Number Required Yes
Side Loop No
Type Of Drain Valve Brass
Uniform Energy Factor (UEF) 3.7
Product Type Water Heater
Collection Smart Hybrid Electric Heat Pump With Anti Leak Technology Voltex XE Al Smart
Width (in) 26.5
Length (in) 26.5
Height (in) 63.18
Weight (lb) 289
Amperage 23.6
Application Residential
Connection Location Both
Diameter (in) 26.5
Energy Star Yes
First Hour Rating (gal.) 82
Number of Elements 2
Parts Warranty 10 Years
Power Source Electric
Tank Warranty 10 Years
Voltage 208 - 240
Wattage 4500
Working Pressure (psi) 150
