A.O. Smith
Sale Conservationist® 75-Gallon Power Vent Commercial Gas Water Heater, 76,000 BTU, 120V, Propane (LP), Indoor, Dual Magnesium Anodes, Side T&P, 2

Conservationist® 75-Gallon Power Vent Commercial Gas Water Heater, 76,000 BTU, 120V, Propane (LP), Indoor, Dual Magnesium Anodes, Side T&P, 2" Insulation, 100311578


Conservationist® 75-Gallon Power Vent Commercial Gas Water Heater, 76,000 BTU, 120V, Propane (LP), Indoor, Dual Magnesium Anodes, Side T&P, 2" Insulation

  • 6201.11$6,201.11
    $9,191.81
  • Currently not in Stock
  • Free Shipping!
  • Brand: A.O. Smith
  • Model # 100311578

Qty

Share by Email Add to Houzz Tweet Pin This Share

Conservationist® Power Vent has a solid state ignition surface that does not flutter or blow out. Provides increased reliability and efficiency over spark ignition systems. Eliminates the pilot and saves energy. Air is precisely drawn through the combustion control port and exhausted through plastic pipe. Controlling the airflow through the heater enhances and regulates the combustion process. In standby mode, the combustion control port restricts air circulation through the heater.

BTF-80 uses up to 76,000 BTU/h of gas to deliver 74 GPH at 100 rise.

A. O. Smith offers the largest commercial product selection available, including the most specified commercial unit in the U.S. We offer more than 500 different commercial models, including gas fired, oil-fired and electric configurations, ranging in capacities from 5 to 10,000 gallons, with input range from 50,000 BTU to the equivalent of 4,000,000 BTU. Our comprehensive line is the natural fit for spec jobs requiring everything from the smallest commercial installation up to the largest multi-structure complex.

Guides & Documents Spec Sheet Manual
All Type Of Item Water Heater
Anode Rod Type Dual Magnesium Anodes
ANSI Standard CSA/ANSI Z21.10.3:19 - CSA 4.3
ASME Certified No
Capacity (Gallons) 75
Classification Commercial Gas Tank
Family Description Conservationist® 75-Gallon Power Vent Commercial Gas Water Heater
Family Name BTF-80
Hazmat No
High Altitude Max 10100 FT
High Altitude Min 0 FT
Installation Type INDOOR
Insulation Thickness (in) 2
Product Tier CONSERVATIONIST
Rated Storage Volume 72
Rating Plate Model Number BTF-80 311
Serial Number Required Yes
Side Loop Yes
Thermal Efficiency 82%
Type Of Drain Valve Brass
Uniform Energy Factor (UEF) 0.69
Product Type Water Heater
Collection Power Vent Conservationist
Width (in) 26
Length (in) 26
Weight (lb) 277
Amperage 5
Application Commercial
BTU/H on High 76000
Connection Location Top
Diameter (in) 26
Energy Star No
First Hour Rating (gal.) 116
Fuel Type Liquified Propane (LP)
Parts Warranty 1 Year
Power Source Gas
Recovery GPH (90 degree F Rise) 84
Tank Warranty 3 Years
Vent Size (in) 5
Venting Type Power Vent
Voltage 120
Working Pressure (psi) 150
