A.O. Smith
Sale ProLine® XE High Efficiency Ultra-Low NOx High Altitude Natural Gas Combi Boiler, 199,000 BTU, Indoor, High Altitude 3,000–9,600 ft, 100297241

ProLine® XE High Efficiency Ultra-Low NOx High Altitude Natural Gas Combi Boiler, 199,000 BTU, Indoor, High Altitude 3,000–9,600 ft, 100297241


ProLine® XE High Efficiency Ultra-Low NOx High Altitude Natural Gas Combi Boiler, 199,000 BTU, Indoor, High Altitude 3,000–9,600 ft

  • 4469.84$4,469.84
    $8,470.99
  • Currently not in Stock
  • Free Shipping!
  • Brand: A.O. Smith
  • Model # 100297241

Qty

Share by Email Add to Houzz Tweet Pin This Share

The ProLine® XE Combi Boiler comes with an industry-leading 4.8 gal/min capacity which means it can deliver reliable hot water for hydronic heat for the entire house in addition to supplying enough domestic hot water for a standard single family home or apartment. The ACB-199H-N indoor residential Ultra-Low NOx Combi Boiler uses up to 199,000 BTU/hr of Natural Gas to deliver a continuous supply of hot water and space heating for homes in high altitude regions. This model is rated at 95% AFUE (Annual Fuel Utilization Efficiency) and is ENERGY STAR® certified, making it eligible for many local utility rebate programs. Its power direct vent design can be vented up to 100 feet using either PVC, CPVC, polypropylene or AL29-4C stainless steel vent pipe, allowing for flexible and easy installation. The user-friendly LCD display provides system status and diagnostic information for easy set up and maintenance. All of these features come with a 10-year limited heat exchanger warranty and 5-year limited parts warranty.

A. O. Smith’s ProLine® water heaters are residential products built to commercial-grade standards and are only available for purchase through professional wholesalers and contractors.

Guides & Documents Spec Sheet Manual Parts List Warranty
All Type Of Item Boiler
ASME Certified Yes
Classification Residential Combi Boiler
Connection Size 0.75 DHW/1.0 Space Heat
Family Description ProLine® XE High Efficiency Ultra-Low NOx High Altitude Natural Gas Combi Boiler
Family Name ACB-199H-N
Hazmat No
High Altitude Max 9600 FT
High Altitude Min 3000 FT
Ignition Type Direct Spark
Installation Type INDOOR
Limited Heat Exchanger Warranty 10 Years
Product Tier ProLine® XE
Rating Plate Model Number ACB-199H-N 110
Serial Number Required Yes
Side Loop No
Vent Material Stainless Steel, polypropylene, PVC, CPVC
22*CSA 4.9 Z21.13:22*CSA 4.9:22
Product Type Boiler
Collection Fire Tube Combi Boiler VC Heat Exchanger ProLine XE
Height (in) 44.25
Weight (lb) 175
AFUE Rating 95
Application Residential
BTU/H on High 199000
BTU/H on Low 19900
Connection Location Bottom
Energy Star Yes
Fuel Type Natural Gas
Parts Warranty 5 Years
Power Source Gas
Vent Size (in) 3
Venting Type Direct Vent
Working Pressure (psi) 50
