A.O. Smith
Sale ProLine® 65-Gallon Direct Solar Water Heater Storage Tank, 66 Gallon, 4.5 kW, 240V, 1-Phase, 1 Element, Indoor, Aluminum Anode, Top T&P, 2

ProLine® 65-Gallon Direct Solar Water Heater Storage Tank, 66 Gallon, 4.5 kW, 240V, 1-Phase, 1 Element, Indoor, Aluminum Anode, Top T&P, 2" Insulation, 100263859


ProLine® 65-Gallon Direct Solar Water Heater Storage Tank, 66 Gallon, 4.5 kW, 240V, 1-Phase, 1 Element, Indoor, Aluminum Anode, Top T&P, 2" Insulation

  • 1608.67$1,608.67
    $2,723.42
  • Currently not in Stock
  • Free Shipping!
  • Brand: A.O. Smith
  • Model # 100263859

Qty

Share by Email Add to Houzz Tweet Pin This Share

The ProLine® 65-gallon direct solar water heaters are designed for installation as a part of a direct (open loop) solar water heating system or for use with external heat exchangers in closed loop systems. The SUN-65 provides storage for the hot water produced by the solar collectors and a supplementary electric heating element that maintains consistent water temperature during periods when solar energy is not available. Count on A. O. Smith for innovative products that provide hot water solutions for residential renewable energy applications.

Environmentally-friendly insulation and factory-installed heat trap nipples reduce heat loss for maximum energy savings.

This ProLine® water heater is designed with A. O. Smith's superior commercial-grade tank protection. Advanced tank features include stainless steel CoreGard™ anode rod, Blue Diamond® glass lining and DynaClean™ automatic sediment-cleaning system, all designed to help protect the tank from the corrosive effects of water and extend the life of the water heater. This model also includes built-in Dry-Fire protection to protect the heating elements from damage during initial start up. All of these features are accompanied by a 6-year limited tank warranty.

A. O. Smith’s ProLine® water heaters are residential products built to commercial-grade standards and are only available for purchase through professional wholesalers and contractors.

Guides & Documents Spec Sheet Manual Warranty
All Type Of Item Water Heater
Anode Rod Type Aluminum Anode
ASME Certified No
Capacity (Gallons) 66
Classification Residential Solar Water Heater Tanks
Family Description ProLine® 65-Gallon Direct Solar Water Heater Storage Tank
Family Name SUN-65
Hazmat No
High Altitude Max 0 FT
High Altitude Min 0 FT
Installation Type INDOOR
Insulation Thickness (in) 2
Phase 1
Product Tier CIRREX
Rating Plate Model Number SUN-65 100
Serial Number Required Yes
Side Loop No
Type Of Drain Valve Brass
Product Type Water Heater
Collection Direct Solar ProLine
Width (in) 22
Length (in) 22
Weight (lb) 152
Application Residential
Connection Location Top
Diameter (in) 22
Energy Star No
Number of Elements 1
Parts Warranty 6 Years
Power Source Electric
Tank Warranty 6 Years
Voltage 240
Wattage 4500
Working Pressure (psi) 150
