A.O. Smith
Sale ProLine® 40-Gallon Mobile Home Direct Vent Tall Natural Gas Water Heater, 32,000 BTU, Indoor, KA-90 Anode, Side T&P, 2

ProLine® 40-Gallon Mobile Home Direct Vent Tall Natural Gas Water Heater, 32,000 BTU, Indoor, KA-90 Anode, Side T&P, 2" Insulation, 100275802


ProLine® 40-Gallon Mobile Home Direct Vent Tall Natural Gas Water Heater, 32,000 BTU, Indoor, KA-90 Anode, Side T&P, 2" Insulation

  • 1276.53$1,276.53
    $2,103.79
  • Currently not in Stock
  • Free Shipping!
  • Brand: A.O. Smith
  • Model # 100275802

Qty

Share by Email Add to Houzz Tweet Pin This Share

The ProLine® 40-Gallon Mobile Home Direct Vent Natural Gas Water Heater is convertible for propane and natural gas and is designed and to meet a wide range of needs of Manufactured Housing installations.

Featuring a 40-gallon (nominal) tank and a 32,000 BTU gas burner, the FMDV-40 Direct Vent delivers a first hour rating of 57 gallons and a recovery rate of 33 gallons per hour. It carries a 6-year limited tank warranty, and meets Low NOx emission requirements.

Environmentally-friendly insulation and factory-installed heat trap nipples reduce heat loss for maximum energy savings.

This ProLine® water heater is designed with A. O. Smith's superior commercial-grade tank protection. Advanced tank features include stainless steel CoreGard™ anode rod, Blue Diamond® glass lining and DynaClean™ automatic sediment-cleaning system, all designed to help protect the tank from the corrosive effects of water and extend the life of the water heater.

A. O. Smith’s ProLine® water heaters are residential products built to commercial-grade standards and are only available for purchase through professional wholesalers and contractors.

Guides & Documents Spec Sheet Manual Warranty
All Type Of Item Water Heater
Anode Rod Type KA-90 Anode
ANSI Standard CSA/ANSI Z21.10.1/CSA 4.1-2019
ASME Certified No
Blanket Included No
Capacity (Gallons) 40
Classification Residential Gas Tank
Connection Size 4-Mar
Family Description ProLine® 40-Gallon Mobile Home Direct Vent Tall Natural Gas Water Heater
Family Name FMDV-40
Hazmat No
Height To Gas Valve (in) 13.75
High Altitude Max 5400 FT
High Altitude Min 0 FT
Ignition Type Pilot with Piezo Igniter
Installation Type INDOOR
Insulation Thickness (in) 2
Mobile Home Compatible Yes
NOx Emissions Low NOx
Product Tier ProLine®
Rated Storage Volume 38
Rating Plate Model Number FMDV-40 250
Serial Number Required Yes
Side Loop No
Type Of Drain Valve Plastic
Uniform Energy Factor (UEF) 0.59
Product Type Water Heater
Collection Mobile Home Direct Vent ProLine
Width (in) 20
Length (in) 20
Height (in) 58.75
Weight (lb) 135
Application Residential
BTU/H on High 32000
Connection Location Both
Diameter (in) 20
Energy Star No
First Hour Rating (gal.) 57
Fuel Type Natural Gas
Parts Warranty 6 Years
Power Source Gas
Tank Warranty 6 Years
Vent Size (in) 4
Venting Type Direct Vent
Working Pressure (psi) 150
