A.O. Smith
Sale ProLine® 40-Gallon Mobile Home Atmospheric Vent Natural Gas Water Heater, 35,500 BTU, Indoor, Aluminum Anode, Side T&P, 2

ProLine® 40-Gallon Mobile Home Atmospheric Vent Natural Gas Water Heater, 35,500 BTU, Indoor, Aluminum Anode, Side T&P, 2" Insulation, 100210506


ProLine® 40-Gallon Mobile Home Atmospheric Vent Natural Gas Water Heater, 35,500 BTU, Indoor, Aluminum Anode, Side T&P, 2" Insulation

  • 1390.38$1,390.38
    $2,364.99
  • Currently not in Stock
  • Free Shipping!
  • Brand: A.O. Smith
  • Model # 100210506

Qty

Share by Email Add to Houzz Tweet Pin This Share

The ProLine® 40-Gallon Mobile Home Atmospheric Vent Natural Gas Water Heater is convertible for propane and natural gas and is designed and to meet a wide range of needs of Manufactured Housing installations.

Featuring a 40-gallon (nominal) tank and a 35,500 BTU gas burner, the FMHR-40 Standard Vent delivers a first hour rating of 59 gallons and a recovery rate of 36 gallons per hour. It carries a 6-year limited tank warranty, and meets Low NOx emission requirements.

Environmentally-friendly insulation and factory-installed heat trap nipples reduce heat loss for maximum energy savings.

This ProLine® water heater is designed with A. O. Smith's superior commercial-grade tank protection. Advanced tank features include stainless steel CoreGard™ anode rod, Blue Diamond® glass lining and DynaClean™ automatic sediment-cleaning system, all designed to help protect the tank from the corrosive effects of water and extend the life of the water heater.

A. O. Smith’s ProLine® water heaters are residential products built to commercial-grade standards and are only available for purchase through professional wholesalers and contractors.

Guides & Documents Spec Sheet Manual Warranty
All Type Of Item Water Heater
Anode Rod Type Aluminum Anode
ANSI Standard CSA/ANSI Z21.10.1/CSA 4.1-2019
ASME Certified No
Blanket Included No
Capacity (Gallons) 40
Classification Residential Gas Tank
Connection Size 4-Mar
Family Description ProLine® 40-Gallon Mobile Home Atmospheric Vent Natural Gas Water Heater
Family Name FMHR-40
Hazmat No
Height To Gas Valve (in) 13.25
High Altitude Max 10100 FT
High Altitude Min 0 FT
Ignition Type Pilot with Piezo Igniter
Installation Type INDOOR
Insulation Thickness (in) 2
Mobile Home Compatible Yes
NOx Emissions Low NOx
Product Tier ProLine®
Rated Storage Volume 38
Rating Plate Model Number FMHR-40 400
Serial Number Required Yes
Side Loop No
Type Of Drain Valve Brass
Uniform Energy Factor (UEF) 0.58
Product Type Water Heater
Collection Mobile Home Atmospheric Vent ProLine
Width (in) 20
Length (in) 20
Height (in) 58.25
Weight (lb) 140
Application Residential
BTU/H on High 35500
Connection Location Both
Diameter (in) 20
Energy Star No
First Hour Rating (gal.) 59
Fuel Type Natural Gas
Parts Warranty 6 Years
Power Source Gas
Tank Warranty 6 Years
Vent Size (in) 4
Venting Type Atmospheric Vent
Working Pressure (psi) 150
