A.O. Smith
Sale ProLine® 100-Gallon Ultra-Low NOx High Recovery Gas Water Heater, 98 Gallon, 75,100 BTU, Natural Gas, Indoor, Aluminum Anode, 1.88

ProLine® 100-Gallon Ultra-Low NOx High Recovery Gas Water Heater, 98 Gallon, 75,100 BTU, Natural Gas, Indoor, Aluminum Anode, 1.88" Insulation, 100113817


ProLine® 100-Gallon Ultra-Low NOx High Recovery Gas Water Heater, 98 Gallon, 75,100 BTU, Natural Gas, Indoor, Aluminum Anode, 1.88" Insulation

  • 3687.06$3,687.06
    $6,864.70
  • Currently not in Stock
  • Free Shipping!
  • Brand: A.O. Smith
  • Model # 100113817

Qty

Share by Email Add to Houzz Tweet Pin This Share

The ProLine® 100-Gallon Ultra-Low NOx High Recovery Gas Water Heater is designed to deliver reliable hot water for large demands. It includes a fully autmatic controls for more accurate temperature control and requires no electrical connections. For added peace of mind, this model includes a fixed automatic safety gas shutoff device.

Featuring a 98-gallon (nominal) tank and a 75,100 BTU gas burner, the GCN-100 standard vent delivers a thermal efficiency of 80%, a Uniform Energy Factor of 0.58, and a recovery rate of 81 gallons per hour. It carries a 6-year limited warranty, and meets Ultra-Low NOx emission requirements.

Environmentally-friendly insulation and factory-installed heat trap nipples reduce heat loss for maximum energy savings.

This ProLine® water heater is designed with A. O. Smith's superior commercial-grade tank protection. Advanced tank features include stainless steel CoreGard™ anode rod, Blue Diamond® glass lining and DynaClean™ automatic sediment-cleaning system, all designed to help protect the tank from the corrosive effects of water and extend the life of the water heater.

A. O. Smith’s ProLine® water heaters are residential products built to commercial-grade standards and are only available for purchase through professional wholesalers and contractors.

Guides & Documents Spec Sheet Manual Warranty
All Type Of Item Water Heater
Anode Rod Type Aluminum Anode
ANSI Standard CSA/ANSI Z21.10.3:19 - CSA 4.3
ASME Certified No
Blanket Included No
Capacity (Gallons) 98
Classification Residential Gas Tank
Connection Size 1/1/2004
Family Description ProLine® 100-Gallon Ultra-Low NOx High Recovery Gas Water Heater
Family Name GCN-100
Hazmat No
Height To Gas Valve (in) 16
High Altitude Max 7700 FT
High Altitude Min 0 FT
Ignition Type Pilot with Piezo Igniter
Installation Type INDOOR
Insulation Thickness (in) 1.88
NOx Emissions Ultra-Low NOx
Product Tier Proline
Rated Storage Volume 95
Rating Plate Model Number GCN-100 100
Serial Number Required Yes
Side Loop No
Thermal Efficiency 81%
Uniform Energy Factor (UEF) 0.58
Product Type Water Heater
Collection Ultra Low NOx High Recovery ProLine
Width (in) 27.75
Length (in) 27.75
Height (in) 66.5
Weight (lb) 322
Application Residential
BTU/H on High 75100
Diameter (in) 27.75
Energy Star No
First Hour Rating (gal.) 120
Fuel Type Natural Gas
Parts Warranty 6 Years
Power Source Gas
Recovery GPH (90 degree F Rise) 82
Tank Warranty 6 Years
Vent Size (in) 5
Venting Type Atmospheric Vent
Working Pressure (psi) 150
