A.O. Smith
Sale ProLine® 30-Gallon Atmospheric Vent Short Natural Gas Water Heater, 32,000 BTU, Indoor, Aluminum Anode, Side T&P, 2

ProLine® 30-Gallon Atmospheric Vent Short Natural Gas Water Heater, 32,000 BTU, Indoor, Aluminum Anode, Side T&P, 2" Insulation, 100323457


ProLine® 30-Gallon Atmospheric Vent Short Natural Gas Water Heater, 32,000 BTU, Indoor, Aluminum Anode, Side T&P, 2" Insulation

  • 1288.24$1,288.24
    $2,120.13
  • Currently not in Stock
  • Free Shipping!
  • Brand: A.O. Smith
  • Model # 100323457

Qty

Share by Email Add to Houzz Tweet Pin This Share

ProLine® 30-Gallon Atmospheric Vent Short Natural Gas Water Heater is designed to deliver an economical performance that can lower your energy bills and also provide long-lasting value.

Featuring a 30-gallon (nominal) tank and a 32,000 BTU gas burner, the GCRL-30R Standard Vent delivers a first hour rating of 55 gallons and a recovery rate of 32 gallons per hour. It carries a 6-year limited tank warranty, and meets Low NOx emission requirements.

Environmentally-friendly insulation and factory-installed heat trap nipples reduce heat loss for maximum energy savings.

This ProLine® water heater is designed with A. O. Smith's superior commercial-grade tank protection. Advanced tank features include stainless steel CoreGard™ anode rod, Blue Diamond® glass lining and DynaClean™ automatic sediment-cleaning system, all designed to help protect the tank from the corrosive effects of water and extend the life of the water heater.

A. O. Smith’s ProLine® water heaters are residential products built to commercial-grade standards and are only available for purchase through professional wholesalers and contractors.

Guides & Documents Spec Sheet Manual Warranty
All Type Of Item Water Heater
Anode Rod Type Aluminum Anode
ANSI Standard CSA/ANSI Z21.10.1/CSA 4.1-2019
ASME Certified No
Blanket Included No
Capacity (Gallons) 30
Classification Residential Gas Tank
Connection Size 4-Mar
Family Description ProLine® 30-Gallon Atmospheric Vent Short Natural Gas Water Heater
Family Name GCRL-30R
Hazmat No
Height To Gas Valve (in) 13
High Altitude Max 10100 FT
High Altitude Min 0 FT
Ignition Type Pilot with Piezo Igniter
Installation Type INDOOR
Insulation Thickness (in) 2
Product Tier ProLine®
Rated Storage Volume 29
Rating Plate Model Number GCRL-30R 400
Serial Number Required Yes
Side Loop No
Type Of Drain Valve Brass
Uniform Energy Factor (UEF) 0.6
Product Type Water Heater
Collection Atmospheric Vent ProLine
Width (in) 20
Length (in) 20
Height (in) 46.5
Weight (lb) 108
Application Residential
BTU/H on High 32000
Connection Location Top
Diameter (in) 20
Energy Star No
First Hour Rating (gal.) 55
Fuel Type Natural Gas
Parts Warranty 6 Years
Power Source Gas
Tank Warranty 6 Years
Vent Size (in) 3
Venting Type Atmospheric Vent
Working Pressure (psi) 150
