Sale Vertex™ 75-Gallon Ultra-Low NOx Power Direct Vent Water Heater, 100,000 BTU, 120V, 1-Phase, Indoor, Powered Anode, Side T&P, 2.63

Vertex™ 75-Gallon Ultra-Low NOx Power Direct Vent Water Heater, 100,000 BTU, 120V, 1-Phase, Indoor, Powered Anode, Side T&P, 2.63" Insulation, 100339249


Vertex™ 75-Gallon Ultra-Low NOx Power Direct Vent Water Heater, 100,000 BTU, 120V, 1-Phase, Indoor, Powered Anode, Side T&P, 2.63" Insulation

  • 5237.15$5,237.15
    $10,050.60
  • Currently not in Stock
  • Free Shipping!
  • Brand: A.O. Smith
  • Model # 100339249

Qty

Share by Email Add to Houzz Tweet Pin This Share

The Vertex™ 75-Gallon Ultra-Low NOx Power Direct Vent Natural Gas Water Heater offers unprecedented levels of performance to meet your hot water needs. Featuring a 75-gallon (nominal) tank and an AiQ - Adaptive Gas Technology allows you to select Natural Gas or Liquid Propane during installation, the HDHE-75 400 series Power Direct Vent delivers a thermal efficiency of 96%, a Uniform Energy Factor of 0.86, and a recovery rate of 150 gallons per hour. It carries a 8-year limited warranty, and meets Ultra-Low NOx emission requirements. Environmentally-friendly insulation and factory-installed heat trap nipples reduce heat loss for maximum energy savings. This Vertex™ water heater is designed with A. O. Smith's superior commercial-grade tank protection. Advanced tank features include stainless steel CoreGard™ anode rod, Blue Diamond® glass lining and DynaClean™ automatic sediment-cleaning system, all designed to help protect the tank from the corrosive effects of water and extend the life of the water heater. A. O. Smith’s ProLine® water heaters are residential products built to commercial-grade standards and are only available for purchase through professional wholesalers and contractors.

Guides & Documents Spec Sheet Manual Parts List Service Handbook Warranty
All Type Of Item Water Heater
Anode Rod Type Powered Anode
ANSI Standard CSA/ANSI Z21.10.3:19 - CSA 4.3
ASME Certified No
Capacity (Gallons) 75
Classification Residential Gas Tank
Connection Size 4-Mar
Family Description Vertex™ 75-Gallon Ultra-Low NOx Power Direct Vent Water Heater
Family Name HDHE-75
Hazmat No
Height To Gas Valve (in) 60
High Altitude Max 10100 FT
High Altitude Min 0 FT
Installation Type INDOOR
Insulation Thickness (in) 2.63
NOx Emissions Ultra-Low NOx
Phase 1
Product Tier VERTEX
Rated Storage Volume 74
Rating Plate Model Number HDHE-75 400
Serial Number Required Yes
Side Loop Yes
Thermal Efficiency 96%
Type Of Drain Valve Brass
Uniform Energy Factor (UEF) 0.86
Product Type Water Heater
Collection Ultra Low NOx Power Direct Vent Vertex
Width (in) 27.75
Length (in) 27.75
Height (in) 65.25
Weight (lb) 388
Amperage 5
Application Residential
BTU/H on High 100000
BTU/H on Low 100000
Connection Location Top
Diameter (in) 27.75
Energy Star Yes
First Hour Rating (gal.) 150
Fuel Type NG/LP
Parts Warranty 8 Years
Power Source Gas
Tank Warranty 8 Years
Venting Type Power Direct Vent
Voltage 120
Working Pressure (psi) 150
