A.O. Smith
Sale ProLine® 100-Gallon High Recovery Atmospheric Vent Natural Gas Water Heater, 98 Gallon, 75,100 BTU, Propane (LP), Indoor, Aluminum Anode, 1.88

ProLine® 100-Gallon High Recovery Atmospheric Vent Natural Gas Water Heater, 98 Gallon, 75,100 BTU, Propane (LP), Indoor, Aluminum Anode, 1.88" Insulation, 100280119


ProLine® 100-Gallon High Recovery Atmospheric Vent Natural Gas Water Heater, 98 Gallon, 75,100 BTU, Propane (LP), Indoor, Aluminum Anode, 1.88" Insulation

  • 4054.04$4,054.04
    $7,210.56
  • Only 1 in Stock
  • Free Shipping!
  • Brand: A.O. Smith
  • Model # 100280119

Qty

Share by Email Add to Houzz Tweet Pin This Share

The ProLine® 100-Gallon High Recovery Atmospheric Vent Natural Gas Water Heater is designed for reliable performance, reduced NOx emissions and has 80% thermal efficiency.

Featuring a 98-gallon (nominal) tank and a 75,100 BTU gas burner, a Uniform Energy Factor of 0.58, and a recovery rate of 81 gallons per hour. It carries a 6-year limited warranty, and meets Low NOx emission requirements.

Environmentally-friendly insulation and factory-installed heat trap nipples reduce heat loss for maximum energy savings.

This ProLine® water heater is designed with A. O. Smith's superior commercial-grade tank protection. Advanced tank features include stainless steel CoreGard™ anode rod, Blue Diamond® glass lining and DynaClean™ automatic sediment-cleaning system, all designed to help protect the tank from the corrosive effects of water and extend the life of the water heater.

A. O. Smith’s ProLine® water heaters are residential products built to commercial-grade standards and are only available for purchase through professional wholesalers and contractors.

Guides & Documents Spec Sheet Manual Warranty
All Type Of Item Water Heater
Anode Rod Type Aluminum Anode
ANSI Standard CSA/ANSI Z21.10.3:19 - CSA 4.3
ASME Certified No
Blanket Included No
Capacity (Gallons) 98
Classification Residential Gas Tank
Connection Size 1/1/2004
Family Description ProLine® 100-Gallon High Recovery Atmospheric Vent Natural Gas Water Heater
Family Name FCG-100
Hazmat No
High Altitude Max 7700 FT
High Altitude Min 0 FT
Ignition Type Pilot with Piezo Igniter
Installation Type INDOOR
Insulation Thickness (in) 1.88
NOx Emissions Low NOx
Product Tier ProLine®
Rated Storage Volume 95
Rating Plate Model Number FCG-100 401
Serial Number Required Yes
Side Loop No
Thermal Efficiency 80%
Uniform Energy Factor (UEF) 0.58
Product Type Water Heater
Collection High Capacity Atmospheric Vent ProLine
Width (in) 27.75
Length (in) 27.75
Height (in) 65
Weight (lb) 340
Application Residential
BTU/H on High 75100
Diameter (in) 27.75
Energy Star No
First Hour Rating (gal.) 170
Fuel Type Liquified Propane (LP)
Parts Warranty 6 Years
Power Source Gas
Recovery GPH (90 degree F Rise) 81
Tank Warranty 6 Years
Vent Size (in) 5
Venting Type Atmospheric Vent
Working Pressure (psi) 150
