A.O. Smith
Sale ProLine® 40-Gallon Atmospheric Vent Short Natural Gas Water Heater, 40,000 BTU, Indoor, Magnesium Anode, Side T&P, 1

ProLine® 40-Gallon Atmospheric Vent Short Natural Gas Water Heater, 40,000 BTU, Indoor, Magnesium Anode, Side T&P, 1" Insulation (GCBL4000L010A19), 100305101


ProLine® 40-Gallon Atmospheric Vent Short Natural Gas Water Heater, 40,000 BTU, Indoor, Magnesium Anode, Side T&P, 1" Insulation (GCBL4000L010A19)

  • 1067.95$1,067.95
    $1,675.10
  • Currently not in Stock
  • Free Shipping!
  • Brand: A.O. Smith
  • Model # 100305101

Qty

Share by Email Add to Houzz Tweet Pin This Share

The ProLine® 40-Gallon Atmospheric Vent Short Natural Gas Water Heater is designed to deliver an economical performance that can lower your energy bills and also provide long-lasting value.

Featuring a 40-gallon (nominal) tank and a 40,000 BTU gas burner, the GCBL-40 Standard Vent delivers a first hour rating of 68 gallons and a recovery rate of 41 gallons per hour. It carries a 6-year limited tank warranty, and meets Low NOx emission requirements. This model ships with a supplied insulation blanket.

Environmentally-friendly insulation and factory-installed heat trap nipples reduce heat loss for maximum energy savings.

This ProLine® water heater is designed with A. O. Smith's superior commercial-grade tank protection. Advanced tank features include stainless steel CoreGard™ anode rod, Blue Diamond® glass lining and DynaClean™ automatic sediment-cleaning system, all designed to help protect the tank from the corrosive effects of water and extend the life of the water heater.

A. O. Smith’s ProLine® water heaters are residential products built to commercial-grade standards and are only available for purchase through professional wholesalers and contractors.

Guides & Documents Spec Sheet Manual Warranty
All Type Of Item Water Heater
Anode Rod Type Magnesium Anode
ANSI Standard CSA/ANSI Z21.10.1/CSA 4.1-2019
ASME Certified No
Blanket Included Yes
Capacity (Gallons) 40
Classification Residential Gas Tank
Connection Size 4-Mar
Family Description ProLine® 40-Gallon Atmospheric Vent Short Natural Gas Water Heater
Family Name GCBL-40
Hazmat No
Height To Gas Valve (in) 12.5
High Altitude Max 10100 FT
High Altitude Min 0 FT
Ignition Type Pilot with Piezo Igniter
Installation Type INDOOR
Insulation Thickness (in) 1
Product Tier ProLine®
Rated Storage Volume 38
Rating Plate Model Number GCBL-40 400
Serial Number Required Yes
Side Loop No
Type Of Drain Valve Brass
Uniform Energy Factor (UEF) 0.57
Product Type Water Heater
Collection Atmospheric Vent ProLine
Width (in) 20
Length (in) 20
Height (in) 47.75
Weight (lb) 134
Application Residential
BTU/H on High 40000
Connection Location Top
Diameter (in) 20
Energy Star No
First Hour Rating (gal.) 68
Fuel Type Natural Gas
Parts Warranty 6 Years
Power Source Gas
Tank Warranty 6 Years
Vent Size (in) 4
Venting Type Atmospheric Vent
Working Pressure (psi) 150
