A.O. Smith
Sale ProLine® XE 50-Gallon High Efficiency Flue Damper Short Natural Gas Water Heater, 40,000 BTU, Indoor, Aluminum Anode, Side T&P, 2

ProLine® XE 50-Gallon High Efficiency Flue Damper Short Natural Gas Water Heater, 40,000 BTU, Indoor, Aluminum Anode, Side T&P, 2" Insulation, 100113430


ProLine® XE 50-Gallon High Efficiency Flue Damper Short Natural Gas Water Heater, 40,000 BTU, Indoor, Aluminum Anode, Side T&P, 2" Insulation

  • 1445.60$1,445.60
    $2,451.27
  • Currently not in Stock
  • Free Shipping!
  • Brand: A.O. Smith
  • Model # 100113430

Qty

Share by Email Add to Houzz Tweet Pin This Share

The ProLine® XE 50-Gallon Atmospheric Vent Short Natural Gas Water Heater with Flue Damper offers highly optimized performance and increased efficiency thanks its automatic flue damper and electronic gas control. The automatic flue damper increases efficiency as it automatically opens and closes to reduce heat loss in the standby mode. While the intelligent control logic provides enhanced operating parameters and tighter differentials for precise sensing and faster heating response to optimize performance. Note, power is required for this model.

Featuring a 50-gallon (nominal) tank and a 40,000 BTU gas burner, the GCFL-50 standard vent delivers a first hour rating of 78 gallons and a recovery rate of 42 gallons per hour. With an 0.69 Uniform Energy Factor, this model carries a 6-year limited warranty, and meets Ultra-Low NOx emission requirements.

Environmentally-friendly insulation and factory-installed heat trap nipples reduce heat loss for maximum energy savings.

This ProLine® XE water heater is designed with A. O. Smith's superior commercial-grade tank protection. Advanced tank features include stainless steel CoreGard™ anode rod, Blue Diamond® glass lining and DynaClean™ automatic sediment-cleaning system, all designed to help protect the tank from the corrosive effects of water and extend the life of the water heater. This model also includes built-in Dry-Fire protection to protect the heating elements from damage during initial start up. All of these features are accompanied by a 6-year limited tank warranty.

A. O. Smith’s ProLine® water heaters are residential products built to commercial-grade standards and are only available for purchase through professional wholesalers and contractors.

Guides & Documents Spec Sheet Manual Warranty
All Type Of Item Water Heater
Anode Rod Type Aluminum Anode
ANSI Standard CSA/ANSI Z21.10.1/CSA 4.1-2019
ASME Certified No
Blanket Included No
Capacity (Gallons) 50
Classification Residential Gas Tank
Connection Size 4-Mar
Family Description ProLine® XE 50-Gallon High Efficiency Flue Damper Short Natural Gas Water Heater
Family Name GCFL-50
Hazmat No
Height To Gas Valve (in) 10.75
High Altitude Max 10100 FT
High Altitude Min 0 FT
Ignition Type Electronic Hot Surface Igniter
Installation Type INDOOR
Insulation Thickness (in) 2
NOx Emissions Low NOx
Product Tier ProLine® XE
Rated Storage Volume 49
Rating Plate Model Number GCFL-50 100
Serial Number Required Yes
Side Loop No
Type Of Drain Valve Brass
Uniform Energy Factor (UEF) 0.69
Product Type Water Heater
Collection Flue Damper ProLine XE
Width (in) 24
Length (in) 24
Height (in) 52.75
Weight (lb) 175
Application Residential
BTU/H on High 40000
Connection Location Top
Diameter (in) 24
Energy Star No
First Hour Rating (gal.) 78
Fuel Type Natural Gas
Parts Warranty 6 Years
Power Source Gas
Tank Warranty 6 Years
Vent Size (in) 4
Venting Type Atmospheric Vent
Working Pressure (psi) 150
