Sale ProLine® XE 40-Gallon Ultra-Low NOx Power Direct Vent Natural Gas Water Heater, 40,000 BTU, 120V, Indoor, KA-90 Anode, Side T&P, 2

ProLine® XE 40-Gallon Ultra-Low NOx Power Direct Vent Natural Gas Water Heater, 40,000 BTU, 120V, Indoor, KA-90 Anode, Side T&P, 2" Insulation, 100330026


ProLine® XE 40-Gallon Ultra-Low NOx Power Direct Vent Natural Gas Water Heater, 40,000 BTU, 120V, Indoor, KA-90 Anode, Side T&P, 2" Insulation

  • 2924.02$2,924.02
    $5,489.87
  • Currently not in Stock
  • Free Shipping!
  • Brand: A.O. Smith
  • Model # 100330026

Qty

Share by Email Add to Houzz Tweet Pin This Share

The ProLine® XE 40-Gallon Ultra-Low NOx Power Direct Vent Natural Gas Water Heater utilizes an innovative burner system, a combination of radiant heat and excess air to comply with Utah, South Coast Air Quality Management District and other California Air Quality Management Districts with similar requirements of less than 10 ng/J for ultra-low NOx emissions.

Featuring a 40-gallon (nominal) tank and a 40,000 BTU gas burner, the GPDNL-40 Power Direct Vent delivers a first hour rating of 74 gallons and a recovery rate of 41 gallons per hour. This model features a 0.70 Uniform Energy Factor and carries a 6-year limited warranty.

Environmentally-friendly insulation and factory-installed heat trap nipples reduce heat loss for maximum energy savings.

This ProLine® XE water heater is designed with A. O. Smith's superior commercial-grade tank protection. Advanced tank features include stainless steel CoreGard™ anode rod, Blue Diamond® glass lining and DynaClean™ automatic sediment-cleaning system, all designed to help protect the tank from the corrosive effects of water and extend the life of the water heater.

A. O. Smith’s ProLine® water heaters are residential products built to commercial-grade standards and are only available for purchase through professional wholesalers and contractors.

Guides & Documents Spec Sheet Manual Warranty
All Type Of Item Water Heater
Anode Rod Type KA-90 Anode
ANSI Standard ANSI Z21.10.1-CSA 4.1-2019
ASME Certified No
Blanket Included No
Capacity (Gallons) 40
Classification Residential Gas Tank
Connection Size 4-Mar
Family Description ProLine® XE 40-Gallon Ultra-Low NOx Power Direct Vent Natural Gas Water Heater
Family Name GPDNL-40
Hazmat No
Height To Gas Valve (in) 13.5
High Altitude Max 5400 FT
High Altitude Min 0 FT
Ignition Type Electronic Hot Surface Igniter
Installation Type INDOOR
Insulation Thickness (in) 2
NOx Emissions Ultra-Low NOx
Product Tier ProLine® XE
Rated Storage Volume 38
Rating Plate Model Number GPDNL-40 100
Serial Number Required Yes
Side Loop No
Type Of Drain Valve Brass
Uniform Energy Factor (UEF) 0.7
Product Type Water Heater
Collection Power Direct Vent Ultra Low NOx ProLine XE
Width (in) 22
Length (in) 22
Height (in) 49.5
Weight (lb) 174
Amperage 5
Application Residential
BTU/H on High 40000
Connection Location Top
Diameter (in) 22
Energy Star No
First Hour Rating (gal.) 75
Fuel Type Natural Gas
Parts Warranty 6 Years
Power Source Gas
Tank Warranty 6 Years
Vent Size (in) 4
Venting Type Power Direct Vent
Voltage 120
Working Pressure (psi) 150
