A.O. Smith
Sale ProLine® XE 75-Gallon Power Direct Vent Natural Gas Water Heater, 76,000 BTU, 120V, Indoor, Dual Magnesium Anodes, Side T&P, 2

ProLine® XE 75-Gallon Power Direct Vent Natural Gas Water Heater, 76,000 BTU, 120V, Indoor, Dual Magnesium Anodes, Side T&P, 2" Insulation, 100304697


ProLine® XE 75-Gallon Power Direct Vent Natural Gas Water Heater, 76,000 BTU, 120V, Indoor, Dual Magnesium Anodes, Side T&P, 2" Insulation

  • 4185.93$4,185.93
    $7,981.83
  • Currently not in Stock
  • Free Shipping!
  • Brand: A.O. Smith
  • Model # 100304697

Qty

Share by Email Add to Houzz Tweet Pin This Share

The ProLine® XE 75-Gallon Direct Vent Natural Gas Water Heater features a two-pipe combustion system that draws clean air from outside the home, eliminating any worries about indoor ventilation.

Featuring a 75-gallon (nominal) tank and a 76,000 BTU propane burner, the GPDX-75L Power Direct Vent delivers a recovery rate of 82 gallons per hour. It carries a 6-year limited warranty, and meets Low NOx emission requirements.

Environmentally-friendly insulation and factory-installed heat trap nipples reduce heat loss for maximum energy savings.

This ProLine® XE water heater is designed with A. O. Smith's superior commercial-grade tank protection. Advanced tank features include stainless steel CoreGard™ anode rod, Blue Diamond® glass lining and DynaClean™ automatic sediment-cleaning system, all designed to help protect the tank from the corrosive effects of water and extend the life of the water heater.

A. O. Smith’s ProLine® water heaters are residential products built to commercial-grade standards and are only available for purchase through professional wholesalers and contractors.

Guides & Documents Spec Sheet Manual Warranty
All Type Of Item Water Heater
Anode Rod Type Dual Magnesium Anodes
ANSI Standard CSA/ANSI Z21.10.3:19 - CSA 4.3
ASME Certified No
Blanket Included No
Capacity (Gallons) 75
Classification Residential Gas Tank
Connection Size 4-Mar
Family Description ProLine® XE 75-Gallon Power Direct Vent Natural Gas Water Heater
Family Name GPDX-75L
Hazmat No
High Altitude Max 10100 FT
High Altitude Min 0 FT
Ignition Type Electronic Hot Surface Igniter
Installation Type INDOOR
Insulation Thickness (in) 2
NOx Emissions Low NOx
Product Tier ProLine® XE
Rated Storage Volume 72
Rating Plate Model Number GPDX-75L 310
Serial Number Required Yes
Side Loop Yes
Thermal Efficiency 82%
Type Of Drain Valve Brass
Uniform Energy Factor (UEF) 0.68
Product Type Water Heater
Collection Power Direct Vent ProLine XE
Width (in) 26
Length (in) 26
Height (in) 60
Weight (lb) 280
Amperage 5
Application Residential
BTU/H on High 76000
Connection Location Top
Diameter (in) 26
Energy Star No
First Hour Rating (gal.) 129
Fuel Type Natural Gas
Parts Warranty 1 Year
Power Source Gas
Recovery GPH (90 degree F Rise) 84
Tank Warranty 6 Years
Vent Size (in) 5
Venting Type Power Direct Vent
Voltage 120
Working Pressure (psi) 150
