A.O. Smith
Sale ProLine® XE 75-Gallon Power Vent Natural Gas Water Heater, 76,000 BTU, 120V, Propane (LP), Indoor, Dual Magnesium Anodes, Side T&P, 2

ProLine® XE 75-Gallon Power Vent Natural Gas Water Heater, 76,000 BTU, 120V, Propane (LP), Indoor, Dual Magnesium Anodes, Side T&P, 2" Insulation, 100310865


ProLine® XE 75-Gallon Power Vent Natural Gas Water Heater, 76,000 BTU, 120V, Propane (LP), Indoor, Dual Magnesium Anodes, Side T&P, 2" Insulation

  • 3229.95$3,229.95
    $5,901.87
  • Only 3 in Stock
  • Free Shipping!
  • Brand: A.O. Smith
  • Model # 100310865

Qty

Share by Email Add to Houzz Tweet Pin This Share

The ProLine® XE 75-Gallon Power Vent Natural Gas Water Heater is engineered to maximize efficiency while offering greater flexibility in installation options.

Featuring a 75-gallon (nominal) tank and a 76,000 BTU gas burner, the GPVX-75L Power Vent delivers a recovery rate of 80.4 gallons per hour. It carries a 6-year limited warranty, and meets Low NOx emission requirements.

Environmentally-friendly insulation and factory-installed heat trap nipples reduce heat loss for maximum energy savings.

This ProLine® XE water heater is designed with A. O. Smith's superior commercial-grade tank protection. Advanced tank features include stainless steel CoreGard™ anode rod, Blue Diamond® glass lining and DynaClean™ automatic sediment-cleaning system, all designed to help protect the tank from the corrosive effects of water and extend the life of the water heater.

A. O. Smith’s ProLine® water heaters are residential products built to commercial-grade standards and are only available for purchase through professional wholesalers and contractors.

Guides & Documents Spec Sheet Manual Warranty
All Type Of Item Water Heater
Anode Rod Type Dual Magnesium Anodes
ANSI Standard CSA/ANSI Z21.10.3:19 - CSA 4.3
ASME Certified No
Blanket Included No
Capacity (Gallons) 75
Classification Residential Gas Tank
Connection Size 4-Mar
Digital Display Yes
Family Description ProLine® XE 75-Gallon Power Vent Natural Gas Water Heater
Family Name GPVX-75L
Hazmat No
Height To Gas Valve (in) 13.75
High Altitude Max 10100 FT
High Altitude Min 0 FT
Ignition Type Electronic Hot Surface Igniter
Installation Type INDOOR
Insulation Thickness (in) 2
NOx Emissions Low NOx
Product Tier ProLine® XE
Rated Storage Volume 72
Rating Plate Model Number GPVX-75L 311
Serial Number Required Yes
Side Loop Yes
Thermal Efficiency 82%
Type Of Drain Valve Brass
Uniform Energy Factor (UEF) 0.69
Product Type Water Heater
Collection Power Vent ProLine XE
Width (in) 26
Length (in) 26
Height (in) 61.25
Weight (lb) 277
Amperage 5
Application Residential
BTU/H on High 76000
Connection Location Top
Diameter (in) 26
Energy Star No
First Hour Rating (gal.) 116
Fuel Type Liquified Propane (LP)
Parts Warranty 6 Years
Power Source Gas
Recovery GPH (90 degree F Rise) 84
Tank Warranty 6 Years
Vent Size (in) 5
Venting Type Power Vent
Voltage 120
Working Pressure (psi) 150
