A.O. Smith
Sale ProLine® XE 40-Gallon Ultra-Low Nox Atmospheric Vent Natural Gas Water Heater, 40,000 BTU, Indoor, Outlet KA-90 Anode, Top T&P, 2

ProLine® XE 40-Gallon Ultra-Low Nox Atmospheric Vent Natural Gas Water Heater, 40,000 BTU, Indoor, Outlet KA-90 Anode, Top T&P, 2" Insulation, 100272476


ProLine® XE 40-Gallon Ultra-Low Nox Atmospheric Vent Natural Gas Water Heater, 40,000 BTU, Indoor, Outlet KA-90 Anode, Top T&P, 2" Insulation

  • 1393.22$1,393.22
    $2,343.63
  • Currently not in Stock
  • Free Shipping!
  • Brand: A.O. Smith
  • Model # 100272476

Qty

Share by Email Add to Houzz Tweet Pin This Share

The ProLine® XE 40-Gallon Ultra-Low Nox Atmospheric Vent Natural Gas Water Heater offers highly optimized performance and increased efficiency thanks its automatic flue damper and electronic gas control. The automatic flue damper increases efficiency as it automatically opens and closes to reduce heat loss in standby mode. The intelligent control logic provides enhanced operating parameters and tighter differentials for precise sensing and faster heating response to optimize performance. Featuring a 40-gallon (nominal) tank and a 40,000 BTU gas burner, the GUF-40 standard vent delivers a first hour rating of 68 gallons and a recovery rate of 42 gallons per hour. With a 0.65 Uniform Energy Factor, this model carries a 6-year limited warranty, and meets Ultra-Low NOx emission requirements. Environmentally-friendly insulation and factory-installed heat trap nipples reduce heat loss for maximum energy savings. This ProLine® XE water heater is designed with A. O. Smith's superior commercial-grade tank protection. Advanced tank features include stainless steel CoreGard™ anode rod, Blue Diamond® glass lining and DynaClean™ automatic sediment-cleaning system, all designed to help protect the tank from the corrosive effects of water and extend the life of the water heater. All of these features are accompanied by a 6-year limited tank warranty. A. O. Smith’s ProLine® water heaters are residential products built to commercial-grade standards and are only available for purchase through professional wholesalers and contractors.

Guides & Documents Spec Sheet Manual Warranty
All Type Of Item Water Heater
Anode Rod Type Outlet KA-90 Anode
ANSI Standard CSA/ANSI Z21.10.1/CSA 4.1-2019
ASME Certified No
Blanket Included No
Capacity (Gallons) 40
Classification Residential Gas Tank
Connection Size 4-Mar
Family Description ProLine® XE 40-Gallon Ultra-Low NOx Atmospheric Vent Natural Gas Water Heater
Family Name GUF-40
Hazmat No
Height To Gas Valve (in) 12.5
High Altitude Max 7800 FT
High Altitude Min 0 FT
Ignition Type Electronic Hot Surface Igniter
Installation Type INDOOR
Insulation Thickness (in) 2
NOx Emissions Ultra-Low NOx
Product Tier ProLine® XE
Rated Storage Volume 38
Rating Plate Model Number GUF-40 100
Serial Number Required Yes
Side Loop No
Type Of Drain Valve Brass
Uniform Energy Factor (UEF) 0.65
Product Type Water Heater
Collection Flue Damper Ultra Low NOx ProLine XE
Width (in) 20
Length (in) 20
Height (in) 58.25
Weight (lb) 151
Application Residential
BTU/H on High 40000
Diameter (in) 20
Energy Star No
First Hour Rating (gal.) 68
Fuel Type Natural Gas
Parts Warranty 6 Years
Power Source Gas
Tank Warranty 6 Years
Vent Size (in) 4
Venting Type Atmospheric Vent
Working Pressure (psi) 150
